Volvo FM 480
*Avg. Ex-Showroom Price
₹ 1.08 Cr
Monthly EMI ₹ 12,000*
*Price is for informational purposes only and the same may be subject to change, For details, please go through the T&C
Volvo FM 480 Key Specifications
Engine Capacity
12800 cc
Power
--
No Of Tyres
14
GVW
59000 Kg
Payload
38810 Kg
Mileage
NA kmpl
Volvo FM 480 Full Specifications
Fuel Type
Diesel
Power
480
Torque
2400Nm
Clutch Type
400 mm dia., Drag type dual friction discs, power assisted
Emission Norm
E-III
Type
Manual
Engine Capacity
12800
Engine Type
Volvo D13A, DI Heavy Duty Turbocharged Intercooled,with Engine Management System (EMS)
Gearbox
14-Speed
No of Cylinders
6
Ground Clearance
390
Fuel Tank Capacity
270
Width
2800
Gross Vehicle Weight
59000
Length
9644
Height
3900
GVW
59000
Wheelbase
6670
Kerb Weight
20190
Payload
38810
Body Type
Rock/Scoop Body
Cabin Type
Day Cabin
Chassis
Chassis with Cabin
Suspension - Front
Leaf springs suspension,Air suspension
Suspension - Rear
Multi leaf springs suspension
Turning Radius
13500
Brakes
Air Brakes
No of Tyres
14
Tyre Size (Rear)
12 x 24
Parking Brake
Yes
Front Axle
First front Axles: Twin heavy-duty straight Axles,Second rear Axle: Heavy-Duty Pressure adjustable Axle
Rear Axle
First rear Axle: Hub reduction Axle,Second rear Axle: Tandem Axle with differential lock
Warranty
NA
Max Speed
50
Gradeability
30
Mileage (kmpl)
NA
