Ashok Leyland Saathi

Applications

E-Commerce And Last-Mile Deliveries, Retail And FMCG Distribution, Agri-Produce Transport, Construction Material Transport, and Waste Management

Ground Clearance (mm)

---

Fuel Tank (Ltr)

40

Width (mm)

1663

Gross Vehicle Weight (Kg)

2288

Length (mm)

4406

Cargo Body Dimensions(LxWxH) (mm)

2500 X 1620 X 380

Height (mm)

1833

Loading Height (mm)

835

Wheelbase (mm)

2250

Kerb Weight (Kg)

1168

Payload (Kg)

1120

Max Speed (Km/h)

80

Mileage (Kmpl)

---

Gradeability (%)

---

Steering Type

Manual Steering

Warranty

5 Years or 2 Lakh Km

Tiltable Cabin

Yes

Front Axle

---

Chassis Type

Chassis With Cabin

Rear Axle

---

Cabin Type

Day Cabin

Front Suspension

Parabolic Leaf Spring (2L) with Double Acting Shock Absorber

Body Type

Deck Body

Rear Suspension

Parabolic Leaf Spring (3L) with Double Acting Shock Absorber

Turning Radius (mm)

4950

Fuel Type

Diesel

Power (HP)

45

Torque (Nm)

110

Clutch Type

215 mm Diameter, Dry Type/Single plate/Mechanical Actuation

Emission Norm

BS-VI

Transmission Type

Manual

Engine Capacity (cc)

1478

Engine Type

1.5 Litres, Turbo Charged, 3 Cylinder Diesel Engine

Gearbox

5 Forward + 1 Reverse

Engine Cylinders

3

Telematics

---

Adjustable Driver Seat

Yes

Seat Belts

Yes

Air Conditioner (AC)

---

Cruise Control

---

Seat Type

Standard Seats

Arm-rest

---

Driver Information Display

Yes

Tiltable Steering

---

Tubeless Tyres

---

Navigation System

---

Seating Capacity

Driver + 1 Passenger

Hill Hold

---

Brakes

Front - Disc Type, Rear - Drum Type (Vacuum Assisted Hydraulic brake with LSPV)

Parking Brake

Yes

ABS

Yes

Number of Tyres

4

Front Tyre Size

165 R14 LT, 8PR

Rear Tyre Size

165 R14 LT, 8PR
